A rafter square, also known as a framing or carpenter’s square, is a versatile tool used in carpentry and woodworking. It typically consists of a flat, L-shaped piece of metal, wood, or plastic. One arm, called the tongue, is longer than the other, called the body. The intersection of the tongue and body forms a 90-degree angle, and the square is marked with various scales and measurements.

Carpenters and builders use the rafter square to measure and mark angles, make straight cuts, check for squareness, and assist in various framing and layout tasks. The tool is particularly useful in roof framing for laying out and cutting rafters, which are the sloping beams that support a pitched roof. The rafter square helps ensure precision and accuracy in construction projects.

Add to compare

Add to wishlist

Description
SAFETY HANDLING PRECAUTIONS

Description

Uses

Measuring and Marking Angles: The rafter square is designed with a 90-degree angle at the intersection of the tongue and body. Carpenters use it to measure and mark various angles accurately, making it a valuable tool for framing and layout work.
Checking for Square: Carpenters often use the rafter square to check if corners and joints are perfectly square. This is crucial in ensuring the structural integrity and stability of a construction project.
Laying Out Rafters: As the name suggests, the rafter square is commonly employed in laying out and cutting roof rafters. It helps carpenters determine the length and angles of the rafters to create a structurally sound roof frame.
Making Straight Cuts: The straight edge of the rafter square is useful for drawing straight lines and making accurate cuts. Carpenters can use it as a guide for sawing or marking materials.
Measuring and Marking Dimensions: The square is marked with scales and measurements, allowing carpenters to measure and mark precise dimensions on materials. This aids in ensuring that components fit together accurately during construction.
Creating 45-Degree Angles: Many rafter squares have markings and features that allow carpenters to easily create 45-degree angles. This is useful in various applications, such as miter cuts for framing or trim work.
Layout Work: The rafter square is a valuable tool for laying out patterns, marking cut lines, and ensuring consistent dimensions in woodworking projects.
Scribing Lines: Carpenters use the rafter square to scribe lines, which involves drawing a line parallel to an edge. This technique is helpful for transferring measurements and ensuring alignment in carpentry work.
Determining Level and Plumb: The rafter square can be used to check for level and plumb, ensuring that surfaces are horizontal and vertical, respectively.
Multi-Functional Use: Some rafter squares come with additional features, such as a level or a protractor, making them even more versatile for various carpentry tasks.

SAFETY HANDLING PRECAUTIONS

Safety Precautions

Personal Protective Equipment (PPE):
- Wear appropriate PPE, including safety glasses or goggles to protect your eyes from dust, debris, or potential flying objects.
- If you're working with power tools in conjunction with the rafter square, wear hearing protection to guard against excessive noise.
Proper Tool Inspection:
- Before use, inspect the rafter square for any damage or defects. Ensure that all markings and measurements are clear and accurate.
Secure Workpiece:
- Securely clamp or otherwise stabilize the workpiece to prevent it from moving during measurement or cutting. This helps maintain control and accuracy while using the rafter square.
Stable Work Surface:
- Work on a stable and level surface to minimize the risk of slips, trips, or falls. Avoid working on uneven or slippery surfaces.
Correct Tool for the Task:
- Use the rafter square for its intended purposes. Avoid using it in ways that may compromise its structural integrity or lead to accidents.
Mindful Handling:
- Handle the rafter square with care, and avoid dropping it, as this can affect its accuracy and usability.
Sharp Tools:
- Ensure that cutting tools used in conjunction with the rafter square are sharp and well-maintained. Dull tools can lead to accidents and imprecise cuts.
Awareness of Surroundings:
- Be aware of your surroundings and the presence of other people. Avoid working in crowded or confined spaces to reduce the risk of accidental collisions.
Secure Storage:
- When not in use, store the rafter square in a safe and designated location. Avoid leaving it in areas where it may pose a tripping hazard.
Read and Follow Instructions:
- Familiarize yourself with the manufacturer's instructions and guidelines for using the rafter square. Follow recommended practices and safety precautions outlined in the user manual.
Use Proper Technique:
- Use the rafter square with the correct technique, and avoid making awkward or unsafe movements. Maintain a stable stance and control the tools with deliberate and precise actions.
Emergency Response:

- Know the location of emergency equipment, such as first aid kits and fire extinguishers, and be familiar with emergency procedures in case of accidents.
